| 参数 | 总容积(L) | 有效容积(L) | 电机及加热功率(KW) | 主轴转速(Rpm) | 外形尺寸(Mm)长×宽×高 |
加热方式 | 卸料方式 |
| 型号 | |||||||
| SHR-5A | 5 | 3 | 1.1 | 1400 | 620×300×730 | 自摩擦 | 手动 |
| SHR-10A | 10 | 7 | 3 | 2000 | 1200×300×830 | ||
| SHR-25A | 25 | 20 | 5.5 | 1440 | 1200×350×850 | ||
| SHR-50A | 50 | 35 | 7/11/3 | 750/1500 | 2100×700×1100 | ||
| SHR-100A | 100 | 75 | 14/22/6 | 650/1300 | 2100×800×1510 | 电 | 手动 |
| SHR-200A | 200 | 150 | 30/42/9 | 475/950 | 2400×850×1580 | ||
| SHR-300A | 300 | 225 | 40/55/9 | 475/950 | 2800×1080×1680 | 汽 | |
| SHR-400A | 400 | 300 | 47/67/12 | 430/860 | 3160×1150×1760 | ||
| SHR-500A | 500 | 375 | 55/75/12 | 430/860 | 3060×1150×1880 | 自摩擦 | 手动 |
| SHR-800A | 800 | 600 | 83/110/15 | 370/740 | 3385×1380×2750 | ||
| SHR-1000A | 1000 | 750 | 110/160/28 | 325/650 | 3460×1140×2900 | ||
| SHR-1300A | 1300 | 975 | 132/200/40 | 250/500 | 3600×1420×3100 |
