Application:
Process pipe,thick-welled purgings,purgings,packing mateials,continuons reclaim of sheet,foam,beled fiber,film fibers,bunpers and instrument panels .The blade are manufactured form high chromium D-2 steel for high strength, maximum breakage resistance,and durability,The design allows for easy replacement.Using the hydraulic system open & close the cover and screen, easy operate and safety. Many different hole sizes of screen for you select.
Main Technical Parameters:
Model |
Motor KW |
Rotor diameter(mm) |
Cutting blade |
Fixer blade |
Capacity(Kg/h) |
PDB1000 |
90 |
650 |
10 |
6 |
800-1000 |
PBG1200 |
110 |
650 |
15 |
15 |
1200-1500 |
PGB1500 |
132 |
650 |
28 |
12 |
1600-2500 |
PGB1600 |
160 |
650 |
28 |
12 |
2800-3500 |
Remarks: Non-standard Specification Shredders can be designed according to customers' requirements.
