Application:
CA series plastic aggregate machine used for plastic processing equipment
1. Aggregate for Powder, fiber, film and foam material
2. Recrystallization for PET flakes
3. Mixed refine thermoplastic and stuffing material
It is applicable to below materials: PE, PP, PC, PS, PA, PET, PVC, ABS, other thermoplastic materials and composite material mixed refine together. If clean or cleaning plastic aggregate, can get the high density particles which have viscosity.
4. This equipment production line adopts PLC automatic control, touch screen display, operation is simple and convenient
5. The machine without heating, adopting friction principle, energy consumption is small, high output
6. The adaptability of machine for material is high, wear parts replaced more convenient
Main Technical Parameters:
| Model |
CA300 |
CA500 |
CA700 |
| Main motor power |
55-90(kw) |
110-160(kw) |
160-250(kw) |
| Materials handled |
Production Capacity(Kg/h) |
Production Capacity(Kg/h) |
Production Capacity(Kg/h) |
| PE Film 20um |
200-600 |
500-1000 |
900-1200 |
| PE Foam |
200-550 |
450-900 |
700-1100 |
| PP Fiber |
150-400 |
300-600 |
600-1100 |
| PS Film |
150-350 |
300-600 |
500-1100 |
| Hard PS Foam |
180-300 |
300-600 |
500-1100 |
| PVC Film |
250-400 |
300-600 |
500-1200 |
| PA Film |
200-450 |
400-900 |
700-1100 |
| PA6 Fiber |
150-450 |
400-900 |
600-1400 |
| Polyester Fiber |
200-450 |
400-700 |
600-1100 |
| Polyester Foam |
100-400 |
300-700 |
500-1000 |
| Polyester Carpet |
100-350 |
300-700 |
600-1100 |
| PP base material |
100-350 |
300-700 |
600-1200 |
| PET bottle flakes |
200-500 |
600-1100 |
900-1600 |
| PET high stretch film |
200-500 |
400-900 |
800-1600 |
Remarks: Non-standard Specification Shredders can be designed according to customers' requirements.
